VGA graphics card on M2 M Key port with Aspeed AST2400 chipset

Can be installed on the M.2 port of PCs (M or B+M), PCIe type, and allows another screen to be connected to the computer.

Compatibility:

Linux :Redhat RHEL3/4/5/6,SUSE SLES 9/10/11 ,Solaris x86 and Linux kernel 5.1 and above.
Windows server: 2025 2022,2019,2016,2008 R2,
2008 X86/X64,2003x86/x64.
Windows client: Win 8, 8.1, 10, 11.

M2 card in 2280 format with heat sink, suitable for 2280 and 22110 slots.

Specifications:

Aspeed AST2400 CHIPSET.

Form-Factor M.2 M KEY PCIe
Input I/F PCI Express1.1
Output I/F D-SUB 15PIN (VGA) port
Resolution WUXGA:1920x1200 32bpp@60Hz
Support widescreen resolutions:
-WXGA : 1280x800 32/16bpp@60Hz
-WXGA+: 1440x900 32/16bpp@60Hz
-WSXGA+: 1680x1050 32/16bpp@60Hz
-FullHD: 1920x1080p 32/16bpp@60Hz
Support 64 x 64 hardware overlay cursor with mono and color formats
Output connector 20pin 1.25mm x2
TDP(include DRAM) – Maximum power consumption : < 2.7W
– Standby power consumption : < 1.0W
– Sleep power consumption : < 0.5W
Dimension (W x Lx H) 22 x 80 x 7.1 mm
